Attention to the design of 5G Pogo pin connector
Although the introduction of high-frequency 5G signals provides many solutions for connectors, the design of 5G connectors also needs to consider more issues. In this article, Wanchang connector manufacturers mainly share the design considerations of 5G connectors.
If the transmission speed specified by the 5G standard is required in consumer-grade products, for this challenge, the connector needs to be carefully designed and manufactured to minimize the impedance change on the transmission line.
In addition, external signals may also be affected, so 5G connectors need to fully protect the system to avoid electromagnetic interference from external signals and capacitive pickup, and ensure signal integrity and shield electromagnetic interference (EMI) under high-speed transmission. ).
In addition, 5G connectors must also adapt to the miniaturized space of modern mobile devices. In addition to the limited shape, 5G connectors must also meet the strict requirements of application parameters, such as voltage standing wave ratio and insertion loss.
A well-designed 5G connector can effectively reduce signal reflection, degradation, and distortion, and make it fully shielded, thereby effectively reducing EMI.
