Spring Pogo Pin connector performance
Spring pogo pin connector is an indispensable part of electronic products. Well-designed can not only save space but also greatly reduce the difficulty of assembly. In recent years, electronic products have developed in a frivolous and small direction. Electronic manufacturers have It saves space and allows the spring thimble connector to fall and quickly unfold. So what are the most basic functions of a spring thimble connector?
1. Task frequency and duration: The spring thimble connector requires repeated plugging and unplugging during the task, so this also has a very strict requirement on the frequency of its task. The service life of the spring thimble can reach 50,000 times.
2. Small size, high density, and lightweight: With the development of modern technology, smart equipment has become smaller and more compact, more functional, and there have been many changes in external appearance, which can cope with spring thimble connection The volume and fineness of the device have high requirements.
3. Fluctuating contact resistance: A small part of the spring thimble connector is used in smart equipment and other smart terminal equipment, so it requires fluctuating current signals and resistances to shake the function of the equipment.
4. Easy to update: With the improvement of skills, the components can be updated even when the spring thimble connector is installed, and new and more perfect components can be used to replace the old ones.
5. Waterproof and moisture-proof: After that, much electronic equipment will regard waterproofing as a selling point. In fact, the spring thimble connector does have this function, and the waterproof and moisture-proof function of the spring thimble connector will be better when used.
6. Mechanical function of the spring thimble: the positive force of the task point of the spring thimble connector exceeds 60g, and the holding force fluctuates at 0.5kgf/pin5.3. Not only this, but the spring thimble also has shock resistance. The spring thimble can achieve 15 minutes of 10～500HZ vibration frequency, 1.2mm amplitude, drop power will not exceed 1μ sec, and contact impedance <100mOhm.
