Robot Pogo pin connector general characteristics
The following is general characteristics of our pogo pins and connectors:
Characteristics:
A. Electrical
1) Operating voltage: 12V.
2) Operating current: 5A~10A Min.
3) Contact resistance: 30mohm Max.
at working height (Quiescence).
B. Mechanical
1) Total stroke: 1.10mm.
2) Working position: 4.5mm.
3) Spring Force:75±25gf at working height
4) Mechanical life: 30,000 cycle min.
C. Material/Finish
1) Plunger: Brass, Plating Min. 0.25um Au over Min. 1.4um Ni.
2) Barrel: Brass, Min. Plating 0.1um Au over Min. 1.4um Ni.
3) Spring: Stainless steel wire.
4) Housing: PA 4.6 + 30% GLASS FIBER; BLACK(UL94V-0)
D. Environmental
1) Storage and operating temperature range:
-40°C~+85°C
2) Humidity range: 10% RH to 90% RH
3) Salt spray: 48-96H
