SMT Pogo Pin 9Pin Pogo Pin Connector
2) Working position: 4.5mm.
3) Spring Force:75±25gf at working height
4) Mechanical life: 10,000 cycle min.
5) Don't exceed the Max. allowed compression.
Send Inquiry
Product Details ofSMT Pogo Pin 9Pin Pogo Pin Connector
SMT Pogo Pin 9Pin Pogo Pin Connector is an essential component in the field of electronic engineering. It is a type of connector that is used to transmit data and power between two electronic devices. This type of connector is commonly used in medical devices, aerospace, automotive, and other high-tech industries.
SMTPogoPin9PinPogoPinConnector consists of two parts, the pogo pin, and the universal connector. The pogo pin is a spring-loaded contact that makes contact with the connector on the other device. The universal connector is the interface that connects the pogo pin with the other device. This type of connector is unique because it can transmit power and data simultaneously, which makes it a versatile and reliable option for many industries.
One of the main benefits of SMTPogoPin9PinPogoPinConnector is its high connectivity. It can transmit data and power with high accuracy and speed, minimizing signal interference and data loss. This makes it suitable for high-speed communication, including fast charging and data transfer.
Another advantage of SMTPogoPin9PinPogoPinConnector is its strong and sturdy structure. The pogo pin is made from high-quality materials that are resistant to wear and tear, making it durable even in harsh environments. The connector is also designed to withstand shock and vibration, providing a long-lasting connection.
In conclusion, SMTPogoPin9PinPogoPinConnector is a vital component in the electronic engineering industry, providing a reliable and efficient way to transmit data and power. Its high connectivity, durability, and versatility make it an ideal choice for many industries. Whether used in medical devices, aerospace, automotive, or other high-tech industries, this type of connector is an essential solution for connecting electronic devices.
We're Pogo pin, original manufacturer:
Pogo Pin
Spring-loaded Pogo Pin contact
Magnetic Pogo pin connector
Pogo pin electrical connector
Pogo pin PCB connector
Pogo pin circular conectors
High current pogo pin for charging
Pogo pin connector
Pogo pin cable
| Materials and plating for Spring Pogo pins | |||
| plunger | Material | BeCu | Most used material for spring pogo pin |
| Material | Pd Alloy | Effective for anti-solder migration. No plating is needed. | |
| Plating | Au Alloy | Hardness is higher than Au(Gold) plating and is effective for anti-solder migration. | |
| Plating | Au(Gold) | Good electric conductivity. | |
| Barrel | Material | Copper | Brass, Phosphor Bronze, Nickel Silver, BeCu |
| Material | Alloy | The barrel was developed by ourselves. Outer diameter is available from 0.11 to 0.42mm | |
| Plating | Au(Gold) | Good electric conductivity. | |
| Spring | ― | Spring Steel Wire (SWP)（Music Wire） | Operating temperature: -45~125℃ |
| ― | Stainless Steel Wire (SUS) | Operating temperature: -45~140℃ | |
| ― | Stainless Steel Wire for high temperature | Operating temperature: -45~200℃, developed by KITA. |
The drawing of this 9pin Pogo pin connector:
Production Machines & Testing Equipment
more than 80 automatic precision lathes
mature and stable manufacturing technology
What We Guarantee:
POGO PIN precision riveting machine
POGO PIN riveting test
Pogo pin Assembly line workshop
Professional technical team
Pogo pin Application:
There are more and more structure engineers who use Pogo pins when designing programs on Pogo pin keyboards, pogo pin keyboard tablets, smartwatches, e-cigarettes, and TWS earbuds.
Quality Assurance System:
Our products have passed ISO9001, ISO14001, and corporate trademark certifications. And passed the Guangdong Province high-tech enterprise qualification certification, the company has 3 invention patents and 18 practical patent qualifications. We are committed to ensuring that our six management systems work closely together to meet customer standards.
Condition of Use Pogo Pin
| Warranty | Stroke Condition | Environmental Conditions | Current and Voltage Condition |
| ・12months (under the following conditions) | ・Probe shall be stroked vertically same direction as the barrel's axis. | General Conditions | ・Current and Voltage shall be impressed only in a stationary position at a recommended stroke. |
| ・Stroke length should not exceed the recommended stroke. | ・Temprature 20～30℃, humidity below 30% | ||
| ・No dust, no corrosive gas, no pollution | |||
| ・Temprature of the probe itself shall be 10～40℃ |
