Ballpoint Plated Gold Pogo Pin

Ballpoint-plated gold Pogo pin

Keeping a stable connection to a moving target can be a challenge, as constant strain on the components can result in the degradation of the materials and the worst case a malfunction. The Ball-Point Connector solves this problem with a radically new design that offers new engineering possibilities and a simplified assembly without cables.

A ballpoint pogo pin with a ball body, including a needle tube, a needle shaft inserted into the needle tube, a spring installed between the needle shaft and the needle tube, the end surface of the needle shaft is inclined, and the outer circumferential surface of the lower part of the needle shaft is formed with an outer edge A round bead is also arranged between the end of the needle shaft and the spring on the raised part; an inner edge raised part is formed on the lower part of the inner wall of the needle tube.

The ball connector design can be effectively used for electronic devices that need to be connected by mobile, easily replacing the unsightly wiring design, and the ball life span is up to 25 kilometers.

Through the above-mentioned structural design, a ball body is arranged between the needle shaft and the spring, and the force of the spring is concentrated at one point, making the contact between the needle shaft and the spring more reliable.

Divided into light steel bead rail and heavy steel bead rail; is the track for the moving parts on its sliding, generally groove, the moving parts end fixed roller, ball or ball, the slide, roller or ball into the track groove, can slide in the groove so that the moving parts on the slide. Steel bead slide rail is the use of high precision steel bead as the ball slide rail, the general slide rail outer strip embedded with a bead, do fix on both sides of the steel bead, the moving parts on the bead, through the steel bead rolling to make the moving parts slide forward, mostly used in cabinets, wardrobe drawers, and toolbox, tool cabinets, fire trucks and so on. Easy to install, easy to dismantle, no tools, smooth and silent are its main features. Ballpoint-plated gold Pogo pin application is used in monitors, 5G Internet of Things, etc.
