Right Angle 9 Pin Pogo Pin 90 Degree Connector
The Right Angle 9 Pin Pogo Pin90 Degree Connector is a highly versatile electrical connector that is often used in electronic devices such as mobile phones, tablets, and laptops. This connector features a 90-degree design with nine pins, allowing for more efficient use of space in cramped electronic devices.
One of the key benefits of the RightAngle9PinPogoPin90DegreeConnector is its ability to provide reliable and consistent data transfer. This connector is designed to ensure that there is minimal interference, even when used in high-speed data transfer applications. This makes it an ideal connector for use in electronic devices that require fast and reliable data transfer, such as smartphones and tablets.
Another important feature of the RightAngle9PinPogoPin90DegreeConnector is its robust construction. This connector is designed to withstand rigorous use over an extended period of time, ensuring that it will last for many years to come. Its durability also makes it an ideal connector for use in harsh environments, such as industrial or military applications.
Thanks to its compact design, the RightAngle9PinPogoPin90DegreeConnector is also highly versatile and can be used in a wide range of electronic devices. Whether you are designing a new smartphone or tablet, or need a reliable connector for an industrial automation application, this connector can meet your needs.
Overall, the RightAngle9PinPogoPin90DegreeConnector is an excellent choice for anyone looking for a reliable and durable electrical connector. With its robust construction, efficient design, and versatility, this connector is sure to meet your needs, whether you are designing consumer electronics or industrial equipment.
We're a Chinese technology company that produces high-quality POGO PIN connectors that integrates design, R&D, manufacturing, electroplating, assembly, packaging, and sales.
| Materials and plating for Spring Pogo pins | |||
| plunger | Material | BeCu | Most used material for spring probes for semiconductors. |
| Material | Pd Alloy | Effective for anti-solder migration. No plating is needed. | |
| Plating | Au Alloy | Hardness is higher than Au(Gold) plating and is effective for anti-solder migration. | |
| Plating | Au(Gold) | Good electric conductivity. | |
| Barrel | Material | Copper | Brass, Phosphor Bronze, Nickel Silver, BeCu |
| Material | Alloy | Barrel developed by ourselves. Outer diameter is available from 0.11 to 0.42mm | |
| Plating | Au(Gold) | Good electric conductivity. | |
| Spring | ― | Spring Steel Wire (SWP)（Music Wire） | Operating temperature: -45~125℃ |
| ― | Stainless Steel Wire (SUS) | Operating temperature: -45~140℃ | |
| ― | Stainless Steel Wire for high temperature | Operating temperature: -45~200℃, developed by ZZTKJ. | |
Right angle Pogo pin production Machines & Testing Equipment
We have our own Machining and turning workshop to control every production process of pogo pin products from the source to the end. Independent research and development of bevel needle cutting technology, high precision of processing, and stable pogo pin products.
Pogo pin production Machines
Pogo pin production Machines
Production Testing Equipment
Customized automatic POGO PIN precision riveting machine, higher accuracy, and consistency, shorter delivery cycle, sample delivery only takes 3 to 5 days.
title1
title1
Applications of our Right angle 9 pin Pogo Pin 90-degree Connector:
It is widely used in magnetic connectors, medical equipment, security equipment, computer digital (tablets, laptops, audio-visual equipment), TWS Bluetooth headsets, smart wearables (bands, watches, VR, AR) ), smart home, smart door locks, smart cameras, smart robots, e-cigarettes, drones, shared charging, printing devices, GPS devices, 5G communications, new energy vehicles, radio frequency antennas, automation, and industrial equipment; aerospace models, Military electronics and communications, etc.;
Test reports about our Right angle Pogo Pin show our quality control:
Plating gold test report
X-RAY test dimensions and appearance of Pogo pin:
We have advanced testing equipment that can perform appearance and size testing, as well as ROHS environmental testing.
About pogo pin Packing:
let me show you the following engineering steps:
Customers Service
What We Guarantee:
Samples not good—refund
Production not good—refund or reproduce
Service not good—discount on orders
The reliable and original Pogo Pin Manufacture!
Our products have passed ISO9001, ISO14001, and corporate trademark certifications. And passed the Guangdong Province high-tech enterprise qualification certification, and we have 3 invention patents and 18 practical patent qualifications. We are committed to ensuring that our six management systems work closely together to meet customer standards
