Plating Gold Metal shrapnel

Our company is a high-tech enterprise specializing in the research, development, and production of dome chips, dome chips, metal film buttons, and precision hardware. We have been serving remote controls, mobile phones, POS machines, walkie-talkies, radios, game consoles, digital cameras, Membrane switches, electronic instrument control panels, and other electronic and electrical products. The company is equipped with a modern standard constant temperature and dust-free production workshop, with automatic stamping equipment, automatic pipeline installation, load tester, life tester, precision image detector, etc. The rigorous quality assurance system ensures the reliability and long-term stability of product quality. It also introduces high-tech talents and relies on the advantages of the modern management systems to quickly and effectively provide electronic manufacturers with dome button solutions. Now it has established long-term and stable interactive cooperative relations with many large domestic electronic manufacturers.

1649409147

Plating Gold Metal shrapnel connector

Metal shrapnel (also known as a metal dome, snap dome) is made of ultra-thin (0.05mm-0.1mm thickness) and ultra-thick (generally higher hardness) stainless steel 301 or 304 materials. The metal dome is an important part of the switch. Metal shrapnel is mainly used in membrane switches, contact switches, PCB boards, FPC boards, medical equipment, and other products.

1649409117(1)

Plating Gold Metal shrapnel connector

The working principle of the metal shrapnel: the metal shrapnel on the membrane button is located on the conductive part of the PCB (mostly above the gold fingers on the circuit board). When pressed, the center point of the shrapnel is concave and contacts the circuit on the PCB, so as to form a loop, the current passes through, and the whole product can work normally.

image (10)

Plating Gold Metal shrapnel connector

General conventional metal shrapnel, according to their different shapes is divided into round metal shrapnel, cross-shaped metal shrapnel, triangular metal shrapnel, and oval metal shrapnel. Diameter from 3mm to 20mm, strength from 100g to 600gf. Of course, if you have special requirements to make according to your drawings, there is no problem.

d53aa956077d69955ddcb3dbaf33126

Plating Gold Metal shrapnel connector

And according to the customer's requirements for resistors, our metal shrapnel also has nickel-plated, silver-plated, gold-plated, and other surface treatments.

a0336cb11f6a0bac568e92ffbeca428

Plating Gold Metal shrapnel connector

Shrapnel material: copper, stainless steel, aluminum alloy, and other metals

Application industry: communication, automobile, sensor, medical electronics, connector, etc.

Shrapnel features high elasticity, anti-fatigue, anti-oxidation, long life, low resistance, etc.

Process characteristics: It is a molding process in which sheet metal material is processed into a specified shape by die stamping.

ae558bb7e9ae3f8ede70d2f26f2a32c

Plating Gold Metal shrapnel connector

Metal shrapnel has electrical and thermal conductivity, corrosion resistance, easy welding, and conduction. Metal shrapnel is commonly used in 3C digital, new energy, mobile phones, and medical precision electronic parts. Usually, the surface needs to be electroplated (such as gold-plated, silver-plated)

0aec167d6b1e6a165c6ee0260e9ab1b
