1. Surface mount
Pogo Pin spring thimble is generally installed in a stable way, and the bottom of the needle tube is designed with a flat bottom, so we can use vertical or horizontal packaging, which makes it easier to solder with PCB. In addition, some needles have positioning needles at the end, so there will be no offset, and the effect will be better.
2. Straight welding tail installation method
Common plug-in package, convenient for welding. In addition, we often use the tail bending plug-in package, which also gives spring thimble manufacturers more options in terms of space utilization.
3. Floating installation
The main choice is the double-head double-acting design, which is more suitable for connection without welding pressure, allowing engineers to make more space flexibility when making two-way board-to-board connections.
There are many other installation methods for pogo pin. We still have to choose according to our actual situation.
