Double Row Spring Loaded Pogo Pin Connector

Double Row Spring Loaded Pogo Pin Connector
A pogo pin connector is a type of electrical connector that consists of spring-loaded pins. Typically used in PCB applications, pogo pin connectors are perfect for applications that require a reliable, durable, and easy-to-use connection point. Double-row pogo pin connectors are becoming increasingly popular in recent years due to their ability to create a higher density of connections in a smaller footprint.

Double Row Pogo Pin Connector Features
The double-row pogo pin connector is a relatively new type of connector in the electrical market. Its pin count ranges from 20 to 200 with a pitch range of 1.00mm to 2.54mm. It is similar to the single-row connector but with double the number of pins, which allows for easier parallel connections. Pogo pin connectors are classified based on their contact type, such as gold-plated, silver-plated, or tin-plated contacts. The pogo pins in these connectors are typically made of stainless steel or brass and have a current rating of 3A to 15A.

Advantages of Double Row Pogo Pin Connector
One of the greatest advantages of the double-row pogo pin connector is its versatility. It can be used in various applications, such as mobile devices, computers, and other consumer electronics. The connector's double-row design allows for greater connection density within the printed circuit board (PCB), which is crucial, especially in designs that require smaller or compact circuit boards.

Another advantage of the double-row pogo pin connector is its robustness. The spring-loaded pins allow for reliable and secure electrical contact resistant to breakage and damage. The design of the connector also ensures that the pins remain in place, even when the connected device undergoes motion or vibration.

In conclusion, the double-row pogo pin connector is a versatile, durable, and reliable connector quickly becoming a popular choice in the electrical market. Its double-row design allows for greater connection density within the PCB, while its robustness ensures a secure connection. With its many advantages, it is expected that this type of connector will continue to gain popularity in the years to come.
