Connector, that is CONNECTOR. Also known as connectors, plugs, and sockets in China. Usually refers to a connector, that is, connecting two active devices to transmit current or signals. Widely used in aviation, aerospace, national defense, and other military systems. Connectors are an integral part of our electronic engineering technicians. The SIM card socket connector is a small connector commonly used in electronic products such as mobile phones and computers. The effect is very simple: create an AC bridge between blocked or isolated circuits in a circuit, allowing current to flow, allowing the circuit to perform its intended function. Connectors are an integral part of electronic equipment. By investigating the current paths, one or more connectors can always be found.
The way and structure of connectors are constantly changing, and the types of connectors are also varied according to different application goals, frequencies, power, application environments, etc. For example, a connector that lights light on a court is very different from a connector for a hard drive and a rocket that lights a rocket. But no matter what kind of connector it is, make sure the electrical connection is smooth and reliable. In general, connectors are not limited to current. In the rapid development of optoelectronic technology, the carriers of signal transmission in optical fiber systems include light, glass, and plastic, but the function of the optical signal is the same as that of a circuit connector.
When designing the signal integrity of the connector, it is necessary to consider: 1. The continuity of the impedance of the entire interconnected transmission line; 2. The crosstalk between the pins of the connector; 3. There are timing requirements, and the delay on the connector should be considered. The analysis method of the connector is basically the same as the general signal analysis method. It uses simulation software to simulate and analyzes the results to draw conclusions.
The model analysis of the connector is the same as the model analysis of the circuit, except that it is important to pay attention to the accurate modeling and simulation of the connector and via effect for predicting the signal quality.
1. Improve the production process The electrical connector simplifies the installation process of electronic products. It also simplifies the mass production process;
2. Convenient maintenance If the electronic components fail, the failed components can be quickly replaced when installing the connector;
3. As skills progress, components can be updated with connectors to replace old ones with new ones
4. Improve design flexibility Using connectors gives engineers greater flexibility when designing and integrating new products and components into systems. As the structure of connectors becomes more and more diverse, new structures and application areas continue to emerge, and it is difficult to get used to trying to deal with classification and naming problems in a fixed form. However, some basic classifications are still useful.
With the development of the smart electronics industry, electronic connectors are also an emerging manufacturing industry.
Our connectors have been focusing on connectors, terminal lines and wiring harnesses for 22 years, integrating development, production, and sales. The company has a team of professionals in machinery, electronic automation, computer, industrial automation, etc., which can not only meet the needs of standardized mass production but also customize non-standard processing according to the special needs of customers!
