New High Current Probe Pogo Pin 32A
The new high-current probe can measure currents up to 32A (international standard) and is fully compatible with the existing GKS series!
The three new series of high-current test probes are fully compatible with the existing spring test probe (GKS) series, and can also be used as low-resistance probes to achieve accurate measurements. The design of the probe conforms to the international standard, and the probe body does not have the kind of pressure collar that the general current needle has.
In order to be able to complete the contact task, each structural series has a different needle shape and elasticity to choose from.
ZZT-100
• 100 Mil grating (2.54 mm)
• Compatible with GKS-100 structure series
• Up to 16 A current-carrying capacity
• Low internal resistance ≤ 10 mΩ to ensure low heat generation and measurement precision
ZZT-003
• 125 Mil grating (3.18 mm)
• Compatible with GKS-003 structure series
• Up to 27 A current-carrying capacity
• Low internal resistance ≤ 10 mΩ to ensure low heat generation and measurement precision
ZZT-004
• 187 Mil grating (4.75 mm)
• Compatible with GKS-004 structure series
• Up to 32 A current-carrying capacity
• Low internal resistance ≤ 10 mΩ to ensure low heat generation and measurement precision
The high-current probes are respectively installed in the contact sockets. The socket can be wired by welding.
