How to use 5G radio frequency pogo pin
1. The thimble should be arranged to keep the ejection force as balanced as possible. The complex structure requires a large demolding force, and the number of sleeves should be increased.
2. Avoid steps or thimbles on inclined surfaces. The top surface of the thimble should be kept as smooth as possible, and the thimble should be placed on the structural component with good strength.
3. When the rubber part has a deep bone position (depth≥20mm) or it is difficult to arrange a dome needle, a flat thimble should be used. When a flat thimble is needed, the flat thimble should be in the form of an insert, so as to facilitate processing.
4. Avoid sharp-pointed steel, thin steel, especially the top surface of the thimble cannot touch the front mold surface.
5. Before arranging the thimble, it is necessary to consider the edge distance between the thimble and the water delivery channel to avoid adverse effects on the processing and water leakage of the water delivery channel.
6. Considering the exhaust function of the 5G radio frequency pogo pin connector, in order to better exhaust the ejector, the ejector pin should be placed in the part that is easy to form a vacuum. For example, at the large plane of the cavity, although the rubber component has a small packaging force, it is very easy to form a vacuum, which in turn leads to an increase in the release force.
7. For plastic parts with appearance requirements, the thimble cannot be placed on the design surface, but other spray methods must be used.
