How to choose a good-quality pogopin connector?
Pogopin connector can be said to be indispensable in our market. With its original good use and quality, it is favored by the majority of users. Then, as the types of goods on the market continue to increase, how do choose good quality pogopin connector?
When choosing a high-quality pogopin connector, we should think about its quality, so the quality guarantee should be based on the processing technology and product quality, and then the precautions in the production. Will we all pay attention to it? Therefore, During the period of buying money, you need to consult a good merchant or go directly to the relevant specialized factory to buy money, which is more secure.
First, let's talk about what a "mini pogo pin" is. "Micro-pogo pin" is also a type of pogo pin, but its size is very small, and the space occupancy rate is very low (it is a very space-saving product on the product connector)
One, the application field of a miniature pogo pin. This is a new connector system suitable for limited space. If the product needs a flat design or the final product is modular, avoid the use of butt connectors, so miniature pogo pins are the best and ideal choice. The connector will be pushed directly onto the contact pads on the printed circuit board.
Second, the product attributes of miniature pogo pins. The rated current can reach 10A, the minimum needle gauge is 0.4mm (through insertion)/0.3mm (surface mount), and the service life exceeds 50,000 times. It has high vibration resistance and is suitable for data transmission or current transmission of light and thin mobile phone modules (displays, audio jacks, charging modules, etc.).
Third. The structure and working principle of the miniature pogo pin. Like ordinary pogo pins, the mini pogo pin connector includes a thin tube containing a spring and a thimble. The spring pushes the needle to the contact pad on the printed circuit board to establish a reliable and vibration-resistant electrical contact.
Micro pogo pin structure
Fourth, custom design. Mini pogo pins can be selected from customized pogo pins, and the use height meets the specification requirements. This product can be applied to a fully automatic assembly line. Optional custom designs, including different shapes of pins and connector rubber shells, protection devices, packaging, or matching female headers.
Fifth. Standard design. Customers can freely choose the design according to the special requirements of the project. In addition to irregular structures, customers can also use spring pin terminals as a new connector standard for single-row, double-row, or multi-row pin products.
