How do the Pogo pin spring pins install on the PCB?
POGO PIN is a very commonly used electronic connector. Its basic structure consists of a turning needle tube, a turning needle, and a compression spring. The mouth of the needle tube is crimped to keep the needle inside the needle tube, and the contact force is provided by the spring to establish an electrical connection between the needle and the docking parts. I believe many people do not know how POGO PIN is welded. Let's find out how the POGO PIN connector is soldered on the PCB?
With the development of the market and the upgrading of products, more and more consumers are not only limited to the multi-function of products but also need fashionable appearance and small and thin appearance. POGO PIN is a very fine probe, and its volume can be very small, so it can reduce the weight of the connector, save space, and have a beautiful appearance when used in precision connectors.
In daily work, there are a lot of customer inquiries, how to use POGO PIN on the product, how to solder it to the PCB board, in fact, during the use of POGO PIN, the male and female ends are docked and the pogo pin compresses a certain stroke (the compression amount is 1.0mm). , elastic force 70g ± 20g). It can be powered on, transmit signals, etc. to achieve various functions.
POGO PIN can be soldered on the PCB to make it fixed, or it can be fixed on the product structure, which requires professional design engineers to solve the problem. And we can really help you, with 10 years of experience in producing POGOPIN spring thimbles, with high quality and quantity. In order to ensure the quality of the products, the details of each processing link must be controlled very well. The spring thimbles we produce have always maintained a leading-edge, have been recognized by some well-known domestic and foreign companies as their connector suppliers, and have established a good reputation.
How are Pogo pin pogo pins installed on PCB?
First, surface mount
The pogo pin is usually installed in a stable way, and the bottom of the needle tube is a flat bottom design, so we can use a vertical or horizontal package, which makes it easier to solder with the PCB. Also, some needles have locating pins on the end so there is no offset and it will work better.
Second, the straight solder tail installation method
Ordinary plug-in package for easy soldering. In addition, we often use tail-end plug-in packages, which also gives pogo pin manufacturers more options in terms of space utilization.
Third, floating installation
Mainly adopts double-head double-acting design, which is more suitable for connection without welding pressure, allowing engineers to have more space flexibility when making two-way board-to-board connections.
The above points are several installation methods of pogo pin spring thimble recommended for you today. There are many other installation methods for pogo pin spring thimble, we still need to choose according to our actual situation.
