High Current Male And Female Pogo Pin Connector

High Current Male and Female Pogo Pin Connector benefits:

It is produced by a complete patented up-drawing method of smelting and melting copper, to large, medium, fine, drawn copper wires, copper wires, a full range of raw materials, copper products, profiles, wires and cables, precision mold design, stamping, precision plastic granulation, and molding,...Etc. fully automated production.

High Current Male and Female Pogo Pin Connector

It is the connector product with the strongest transmission capacity among all connector product types at present. It is mainly used in power systems, communication networks, financial manufacturing, elevators, industrial automation, medical equipment, office equipment, home appliances, military manufacturing, and other industries.

With the development of electronic products towards smaller, lighter and thinner, the corresponding connectors have also been changed in accordance with the needs of the market. The commonly used board-to-board connectors on the market, as shown in Figure 6, include a male connector and a female connector that is plugged into each other, and two circuit boards that connect the male connector and the female connector respectively. The structure and layout of the existing connectors and the circuit boards are all large. When mating, the male connector must be inserted into the female connector to realize the electrical connection of the two circuit boards, and then fasteners are used. Fix two circuit boards to achieve better mechanical and electrical performance.

It can be seen from the above-mentioned connector structure and drawings that the existing board-to-board connectors still have the following technical problems in practical applications: the male connector and the female connector are oppositely inserted in the form of board-to-board, So that the two circuit boards are connected together in the horizontal direction, which increases the connection length of the circuit board, and the size of the circuit board is fixed according to the specifications, which undoubtedly increases the length and the length of the connector product as a whole. The volume and the large installation space occupied are not conducive to the development of connector products to the trend of miniaturization, and cannot better meet the market demand.
