5A 3in1 High Current Charging Cable

5A 3in1 HighCurrentChargingCable is a powerful and versatile charging cable that is designed to meet the charging needs of multiple devices. It is a USB-C to USB-A charging cable that comes with three different connector tips, including a Lightning, Micro USB, and Type-C tip.

The cable has a high current output of up to 5A, which means it can charge your devices quickly and efficiently. This is particularly useful when you need to quickly charge your phone or tablet, especially when you're on the go.

The three different connector tips mean that you can charge a range of different devices with this one cable. Whether you have an iPhone, an Android phone, or a tablet that uses a Type-C connector, this cable has you covered.

In addition to being versatile, this cable is also built to last. It is made from high-quality materials, including a braided nylon exterior that resists fraying and tangles. The connectors are also sturdy and durable, which means you won't have to worry about them wearing out or breaking over time.

Overall, the 5A3in1HighCurrentChargingCable is an excellent charging cable that is perfect for anyone who needs to charge multiple devices quickly and efficiently. With its high current output and three different connector tips, this cable is a must-have for anyone who wants to simplify their charging setup and stay connected on the go.

In the era of fast charging, all mobile phone manufacturers have magic weapons. There are no less than 5 fast-charging protocols on the market. Among them, Huawei & Honor series have been using their own HiSilicon FCP fast charging (9V2A), and the recently launched annual flagship Mate 9 is equipped with 5A high current charging protocol HUAWEI SuperCharge. Thanks to the use of the Type-C interface, it can provide an overcurrent capability of up to 5A without major changes to the interface. Our 5A high current fast charging data cable is fully compatible.

5A 3in1 High Current Charging Cable

From the USB head, you can see a few thick gold-plated contacts inside. The contact point of port C is also gold-plated. Directly remove the wire, cross-section of the wire, and find two thick two red wires, accounting for almost half of the entire wire, which should be to ensure the passage of high current.

5A 3in1 High Current Charging Cable

The glue at the handle is cut open, and the inside is a steel sleeve. This structure is similar to Apple's lightning wire method, which is rarely seen in other wires. On the other hand, the riveted steel sleeves look solid. The craftsmanship of structural solder joints is very high, and it is worthy of being produced by major manufacturers.

5A 3in1 High Current Charging Cable

The steel sleeve is welded on the head of the Type-C interface in a two-layer structure. Remove the steel sleeve, which is filled with hard glue, an additional reinforcing structure, which also protects the PCB inside. The steel sleeves are all removed, and the whole milky white hard glue is filled. Where the head touches is gold plated.

5A 3in1 High Current Charging Cable

Contact details, gold plated sturdy. We use the USB 2.0 wire specification to achieve 5A high-current fast charging, which has attracted our attention; industry engineers learned that the gold-plated thickness of the interface of the ordinary USB2.0 data cable is 2u, while the gold-plated thickness of our data cable is as high as 32u, which is sufficient It is 15 times more, it can be seen that in order to meet the demand for fast charging, a lot of effort has been made in the use of materials. In addition, the wire diameter of the cable is also thickened.

5A 3in1 High Current Charging Cable

The specifications of the two red cables of the current are as high as 18AWG (number), which is much thicker than the ordinary 20AWG and 22AWG; the smaller the AWG value here, the thicker the wire diameter.

5A 3in1 High Current Charging Cable

Summarize:

(1) Our SuperCharge 5A fast charging cable does not use the USB3.0 specification, nor does it use a custom cable similar to VOOC, which lowers the threshold for users to purchase fast charging accessories;

(2) Our 5A line actually supports Qualcomm QC3.0, MTK PE, and our own FCP fast charge, with good compatibility;

Finally, the workmanship of this line is still good, and the price is also very good. It is also good for regular lines.
